Eliwell - IDNEXT 978 P/C refrigeration controller
Eliwell - IDNEXT 978 P/C refrigeration controller
Couldn't load pickup availability
Electronic controller for refrigerating units, compatible with flammable refrigerant gases. 230V power supply
DESCRIPTION :
IDNext 978 P/C is an electronic controller for static and ventilated units at normal or low temperature with 4 relay outputs and 2 temperature sensors.
The addition of ' /C ' in the descriptive abbreviation indicates that the device mounts the RTC (Real-Time Clock).
The IDNext series is suitable for use on units that use flammable refrigerants in category 2L or 3 such as R290 or R600.
Each device has 3 predefined Applications AP1, AP2, AP3 which pre-configure the device to work with 3 real situations of use, reducing installation times and requiring only punctual modifications of the parameters.
TECHNICAL DETAILS :
| Dimensions |
80.5 x 34.5 x 60.5mm
|
| Drilling template | 71x29mm |
|
Diet
|
230V, 50/60Hz
|
| Analog inputs |
2 x PTC or NTC or Pt1000 (not included)
|
| digital inputs | 1 x WILD |
| Digital outputs |
4 relays:
|
| Serial ports |
1 x TTL for connection to Unicard or to TelevisSystemModBus supervisor
|
| Functions | Multi map; Clock (RTC) |
| Connectivity | Compatible with the Eliwell AIR APP and with the Cloud TelevisAir solution. |
